Can You Build on a Plot in Nagpur? FSI, Setbacks, Road Width and Construction Permission

Buying a residential plot does not mean one can go ahead and construct the entire area of the plot with a building. Factors such as FSI, plot dimensions, required setbacks, adjacent road width and terms and conditions of development in that location would influence actual construction area on the plot.

For people buying a plot to build a house, these are factors that one should find out before they plan to buy plot in Nagpur. For example, two plots of the same area can give you totally different construction options.

What Determines How Much You Can Build?

Any house design will need to begin with confirmation that the plot can be used for residential purposes and is within a suitable planning framework. Subsequently, all new buildings must comply with the provisions of the local authority that the plot is in.

In the case of a plot within Nagpur city, planning would be governed under Nagpur Municipal Corporation’s development control regulations. For plots outside the city within the notified Nagpur Metropolitan Area, development would be governed under rules framed by NMRDA - Special Planning Authority for said area. An architect would then assess the applicable FSI, setbacks, height, access and other restrictions for development on the plot.

How FSI Affects the Buildable Area

Floor Space Index (FSI) is a parameter which determines the maximum allowable floor area for a plot to be developed.

To illustrate how to calculate the FSI admissible above, assume a plot size of 1,250 sq. m. The calculation for the FSI admissible is as follows:

1,250 × 1.10 = 1,375 sq. ft. of FSI area

However, the FSI entitlement calculated does not necessarily mean that every plot of 1,250 sq.ft. in the city of Nagpur shall be entitled to FSI of 1.10. Rather, the entitlement shall depend upon various factors, including road width, zone, etc., whether additional FSI can be granted or not and whether TDR can be allowed or not.

As per the existing UDCPR guidelines, FSI is permissible in an increased ratio based on the width of the road in non-congested areas only.

*These are general UDCPR limits for different categories of plots. The maximum FSI under the Act is not granted to every plot. In addition to the Basic FSI, premium FSI, TDR and other provisions may apply, subject to the conditions and approvals stipulated under the applicable regulations.

How Setbacks and Plot Dimensions Affect the House Footprint

While Floor Space Index (FSI) regulates the total area which can be constructed, the plot restrictions such as setbacks from plot boundaries control the exact location of the building on site. Restrictions on front, side and rear open spaces affect the ground floor area that can actually be used on the plot.

For residential plots in non-congested areas, the UDCPR provides general requirements, subject to the applicable development control provisions and site conditions:

These figures show why plot area alone does not tell you what kind of house can be constructed. The frontage and depth of a plot matter for setbacks. Thus, two plots of 1,500 sq. ft. each can have very different characteristics for the usable area of a building for the same plot dimensions.

The height of the building can also impose additional requirements. More space at the side or rear could be required for a taller building, in addition to space for parking, for fire-fighting equipment, for road widening, for high-tension lines, for water features on the site or for other site-specific reasons in accordance with the overall planning objectives.

What Is Required for Construction Permission in Nagpur?

After you have purchased your residential plot and it has been approved, plans for the proposed house must be drawn up by an authorised architect or a licensed technical professional and then submitted to the competent authority for approval before you can start building.

NMRDA’s building-plan checklist includes the following information amongst others for plotted development:

• Final approved subdivision or layout plan
• Release documentation where applicable
• Site and location plans
• Proposed floor plans, sections and elevations
• FSI calculations
• Road width
• Nearby waterbodies, nalas or high-tension lines
• Applicable safety or buffer distances

The authority will verify the plans for the building that you wish to construct, not just verify that the land you have purchased is an approved residential plot.

For any new construction within the Nagpur Municipal Corporation limits, you will have to complete the NMC building-permission process and adhere to the completion and occupancy requirements of NMC.

Why Plot Size Should Not Be the Only Buying Criterion

Even if the buyer of a plot is going to construct a house on it, they should not concentrate on the headline plot area. They should find out more about the other plots before they make a decision.

• Plot width and depth
• Width of the adjoining road
• Required setbacks
• Permissible FSI
• Approximate ground-floor footprint
• Permitted height or floors
• Any restrictions affecting the site

For example, HOABL Nagpur plots start from 116 sq. metres (around 1,250 sq. ft.). Understand what sort of house you can build on such a plot by studying the sanctioned dimensions of the plot, the plot’s position in relation to the adjoining road, and the setbacks permitted by the sanctioned plan.

Check the Buildable Area Before Designing the House

Review the basic planning requirements for the given plot prior to finalising the detailed architectural plans. FSI alone indicates the overall potential of development for a plot but also needs to comply with various parameters including setbacks, road width requirements, maximum permitted height and other conditions applicable to the plot.

For example, the Floor Space Index (FSI) may permit a certain amount of floor area for a proposed home on a particular plot, but when applied to the plot dimensions and required open spaces, the ground floor area may be less than calculated. Subsequent floors may be added up to the maximum permitted height for the building.

Conclusion

Building on a plot in Nagpur is not merely a function of the land size. While FSI and plot size measure the total permitted floor area, setbacks and road width define how that floor area can be distributed across the plot.

A clear understanding of the plot dimensions and other constraints such as road width and building restrictions, and the permissible construction as per applicable laws, will enable buyers to ascertain how much can actually be constructed on the plot.

FAQs

Is a 1,250 sq. ft. plot large enough to build a house in Nagpur?

In non-congested residential locations on roads less than 15 metres wide, UDCPR may permit a minimum plot area of 80 sq. metres, whereas 1,250 sq. ft. is equivalent to 116 sq. metres. While one can plan a house on such areas, the actual plan would depend upon dimensions of land, front and side setbacks, width of road in front and other terms and conditions of the plan as stipulated in the UDCPR or development control rules of the location.

Can I use the entire permissible FSI on the ground floor?

Not necessarily. The total permissible Floor Space Index under building regulations is sometimes constrained by other requirements such as building line/setback and road width restrictions. The entire FSI may not be usable as Ground Floor.

What happens if I change the house plan after it has been approved?

Material changes to approved plans may require revised approval by the competent authority. It is recommended that the architect/authorised person responsible for the project verify whether additional approval is required for such changes prior to commencing construction.
